Cast iron enclosure high voltage motors with a modular cooling approach. designed for high power pump, fan, and compressor applications, particularly in the water and wastewater industries, power production, and desalination plants. These motors stand out for their excellent quality and dependability while also being reasonably priced because they concentrate on the important things.
Benefits at a glance
Centred on characteristics that are necessary for high power pumps and compressors
- Low lifespan costs due to dependable quality
Robust design and low-wear components
- dependable and long-lasting
Incredibly little design
- Minimal space needs and simple plant integration
Variable in terms of voltage, cooling idea, and number of poles
- precisely tailored solutions for each unique situation
Superior coating systems
- high availability even in challenging environmental circumstances
Technical data overview
| Power range |
0.25 – 7.35 MW |
|---|---|
| Shaft height |
355 – 630 mm |
| Rated speeds |
750 – 3600 rpm |
| No. of poles |
2 – 16 |
| Rated voltages |
up to 11 kV |
| Protection |
IP23, IP24W, IP55 |
| Cooling type |
IC 611, IC 616, IC 81 W, IC 86 W, IC 01 |
| Explosion protection |
Zone 1: Ex pxb, Ex pzc Zone 2: Ex e |
